You can update the layout of a section view group to reset the location of section views that were moved out of place, or to update the layout due to another change, such as a change in a style or the change in the size of a section or of a drafting buffer. When updating the section view sheet layout, resized or inserted section views are respected. The section view for station 3+00 was moved to the next sheet. You can choose to keep the existing stylization, as shown in this example, or you can choose to apply the stylization of the destination section view group to the moved sections. The following illustration shows the section view inserted into the section view group. Its station is 1+75 so it will be inserted between the sections for station 1+50 and 2+00. In the following example, an individual section SL-25 needs to be moved into the section view group. If the styles are different, the section views you are moving can keep their existing styles, or they can use the style of the destination section view group.They are inserted between existing section views in the group as needed so all the section views are in order. The section views are inserted into the section view group in order of their stationing.Section views can be moved from the individual section views collection to a section view group, or from one section view group to another section view group.The section views that you want to move and the destination section view group must share the same sample line group.
Move section views between section view groups:
